Your settings. On the equipment.
View and adjust flow, the blood-to-anticoagulant ratio and volumes. Monitored pressure is displayed on the device.
FLOW / K / VOLUME / MODE / PRESSURE
Technical specificationsApheresis TechnologyMembrane plasmapheresisGEMMA
GEMMA
Membrane plasmapheresis. Portable. 8 kg.
Membrane plasmapheresis engineered for the point of care: one or two needles, configurable flow from 2 to 200 mL/min and monitoring on the device itself. Equipment, consumables and training in one programme.
- Portable
- One or two needles
- Membrane filtration
- Weight
- 8 kg
- Flow range
- 2–200 mL/min
- Operating modes
- Single / double needle
Institutions where GEMMA is in service
GEMMA / 01—06
Why choose GEMMA?
Six engineering decisions that make membrane plasmapheresis simpler to place, set up and run. Each one is documented in the manufacturer's brochure.
8 kgPortable
Portable. 8 kg.
It moves between treatment rooms and to the bedside, so the procedure goes where the patient is.
320 × 200 × 200 mmOne needle is an option.
Single- and two-needle modes let your team match vascular access to each patient and protocol.
One / two needlesMembrane plasma filtration.
Separation by membrane, not by centrifugation, with compatible PFM-500 and PFM-800 filters.
PFM-500 / PFM-800Every setting in plain sight.
Flow, volumes and monitored pressure are set and read directly on the device.
Configurable blood flow: 2–200 mL/minSafety built in.
Air detection, pressure monitoring, automatic stops under defined conditions, and audible and visual alarms.
Detect · block · stop · resolveOne programme, one partner.
Equipment, circuits, filters and hands-on training, planned together for your site.
Setup · training · implementation
Manufacturer brochure · GEMMA, pp. 3–4, 6–12. Configuration and site requirements apply.
When every centimetre counts.
Space, mobility and access decide where a procedure can happen. GEMMA was designed around all three.
| The practical challenge | What GEMMA offers |
|---|---|
| Making room for larger equipment | A 320 × 200 × 200 mm device that fits an existing room. |
| Moving equipment between rooms | 8 kg: one person moves it between rooms. |
| Matching access to the protocol | One- and two-needle modes on the same device. |
GEMMA specifications are taken from the manufacturer's brochure. Other devices vary by model and configuration.
Need a second filtration stage?
The SM-PF-01U configuration supports an optional second stage, such as selective filtration or hemosorption. Discuss the circuit and consumables your protocol needs with our team.
Explore configurationsGEMMA / Portable by design
Plasmapheresis where the patient is.
8 kg and the size of a small case. GEMMA travels with the clinical team, to the patient’s home, the clinic or the hospital, so the procedure goes to the patient.
See every specification
- light enough for carry-on luggage
- 8kg
- single venous access with the one-needle mode, minimally invasive
- 1access
- for a typical procedure, depending on the protocol
- ≈40min
- plasma is separated by a membrane
- 0centrifuges
- monitors air and pressure and stops itself when needed
- Auto
GEMMA / Original media
GEMMA in action.
Real procedures and setup, recorded with GEMMA. See how it works before you arrange a demonstration.
Complete Plasmapheresis Procedure · Original media
GEMMA / Hardware
Portable. Flexible. Adjustments in plain sight.
Use GEMMA with one or two needles and see flow, volumes and monitored pressure on the equipment itself.
One or two needles. Your protocol.
GEMMA offers one- and two-needle operating modes. The clinical team chooses the access and parameters for each procedure.
Single / double needle
8 kg. Ready to move between rooms.
A compact format weighing 8 kg for suitable clinical spaces. Plan power, setup and consumables with our team.
8 kgBrochure specification
GEMMA / Active safety
Safety engineered into the workflow.
- 01
DETECT
Monitor conditions.
- 02
BLOCK
Interrupt reinfusion.
- 03
STOP
Stop the pumps.
- 04
RESOLVE
Guide the response.
Manufacturer documentation · GEMMA · pages 4, 6–7
A complete, connected platform.
Device, circuit, filters and implementation, specified to work as one configuration.
FLOW · K · VOLUME · MODE
Pumps02 / Original 3D model
Understand the object. Explore the original model.
Rotate the existing scan, inspect its views and return to the technical product information.
Explore in 3DOriginal scan · model dimensions are not a procurement specificationPlasmaNexus / Software
Clinical operations, in view.
Procedure records, protocols and consumables. The digital layer around the clinical workflow.
PlasmaNexusOperational workflow
Workflow illustration
Procedure records
Session documentation
- Registration
- Protocol
- Procedure
- Record
Information structure
- Protocol
- Protocol management
- Consumables
- Consumables control
- Traceability
- Record organization
GEMMA
Device-side procedure control
GEMMA keeps flow, mode and pressure indication on the equipment.
PlasmaNexus
Workflow-side organization
PlasmaNexus presents the operational context for records, protocols and consumables.
Original interface image
Original demonstration material in Spanish. Embedded figures are illustrative; this is not live clinical data.
GEMMA / Implementation
From purchase to your first procedure.
- 01
Equipment acquisition
- 02
Dates and training
- 03
First procedure on day one
- 04
Autonomy from day two
- 05
Support 24/7
Manufacturer documentation · GEMMA · pages 8–12
Documentation & science
The source behind the system.
Selected technical documents and original therapeutic apheresis literature.
The source behind the system
Plasmapheresis. Therapeutic apheresis
The reference book on therapeutic plasmapheresis that our clinical training is built on.
Dr. Gerardo Germán Zumbana López · Dr. Valery Alexandrovich Voinov
First edition · EDINO · Guayaquil and Saint Petersburg · 2016 · Original Spanish edition
